SERİ SERIE |
SIZE INCH |
KOD CODE |
PN BAR |
A |
B |
C |
D |
E |
F |
G
|
H |
I |
L |
M |
|
3000 PSI |
3/8" |
BPSAESR310 |
350 |
17,5 |
13 |
36 |
16 |
18 |
14 |
M8x30 |
57 |
38,1 |
47 |
17,5 |
|
1/2" |
BPSAESR315 |
350 |
21,6 |
13 |
36 |
16 |
18 |
14 |
M8x30 |
57 |
38,1 |
47 |
17,5 |
|
|
3/4" |
BPSAESR320 |
350 |
27,2 |
19 |
36 |
18 |
18 |
16 |
M10x35 |
66 |
47,6 |
49 |
22,3 |
|
|
1" |
BPSAESR325 |
320 |
34,1 |
25 |
38 |
18 |
18 |
16 |
M10x35 |
70 |
52,4 |
53 |
26,2 |
|
|
1 1/4" |
BPSAESR332 |
280 |
42,8 |
31 |
41 |
21 |
20 |
18 |
M10x35 |
80 |
58,7 |
69 |
30,2 |
|
|
1 1/2" |
BPSAESR340 |
210 |
48,6 |
38 |
44 |
25 |
22 |
18 |
M12x45 |
94 |
69,9 |
77 |
35,7 |
|
|
2" |
BPSAESR350 |
210 |
61,0 |
50 |
45 |
25 |
24 |
18 |
M12x45 |
103 |
77,8 |
89 |
42,9 |
|
|
2 1/2" |
BPSAESR365 |
175 |
76,6 |
63 |
50 |
25 |
28 |
18 |
M12x45 |
115 |
88,9 |
101 |
50,8 |
|
|
3" |
BPSAESR380 |
160 |
90,5 |
73 |
50 |
27 |
28 |
25 |
M16x50 |
135 |
106,4 |
124 |
61,9 |
|
|
3 1/2" |
BPSAESR390 |
35 |
103,0 |
89 |
50 |
27 |
28 |
25 |
M16x50 |
153 |
120,7 |
136 |
69,9 |
|
|
4" |
BPSAESR3100 |
35 |
115,3 |
99 |
50 |
27 |
28 |
25 |
M16x50 |
163 |
130,2 |
147 |
77,8 |
|
|
5" |
BPSAESR3125 |
35 |
142,0 |
120 |
50 |
28 |
28 |
25 |
M16x55 |
184 |
152,4 |
180 |
92,1 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
6000 PSI |
3/8" |
BPSAESR610 |
420 |
17,5 |
13 |
36 |
16 |
18 |
14 |
M8x30 |
57 |
40,5 |
47 |
18,2 |
|
1/2" |
BPSAESR615 |
420 |
21,6 |
13 |
36 |
16 |
18 |
14 |
M8x30 |
57 |
40,5 |
47 |
18,2 |
|
|
3/4" |
BPSAESR620 |
420 |
27,2 |
19 |
36 |
19 |
20 |
16 |
M10x35 |
71 |
50,8 |
53 |
23,8 |
|
|
1" |
BPSAESR625 |
420 |
34,1 |
25 |
44 |
24 |
22 |
19 |
M12x45 |
80 |
57,2 |
66 |
27,8 |
|
|
1 1/4" |
BPSAESR632 |
420 |
42,8 |
31 |
44 |
27 |
22 |
22 |
M14x45 |
94 |
66,6 |
77 |
31,8 |
|
|
1 1/2" |
BPSAESR640 |
420 |
48,6 |
38 |
51 |
30 |
24 |
24 |
M16x55 |
106 |
79,3 |
89 |
36,5 |
|
|
2" |
BPSAESR650 |
420 |
61,0 |
50 |
70 |
37 |
25 |
32 |
M20x70 |
135 |
96,8 |
116 |
44,5 |
|
|
2 1/2" |
BPSAESR665 |
320 |
76,6 |
63 |
75 |
45 |
28 |
40 |
M24x80 |
166 |
123,8 |
150 |
58,7 |
|
|
3" |
BPSAESR680 |
320 |
90,5 |
73 |
90 |
55 |
30 |
55 |
M30x100 |
208 |
152,4 |
178 |
71,4 |
